Grill dimensions?

htmlprofessional

New Member
Joined
May 29, 2026
Threads
1
Messages
4
Reaction score
0
Location
MT
Vehicles
audi
Slatelets and headlight covers look pretty easy to design and print. Any info on the dimensions of the area between the headlights? I'm guessing we'll have to break it up into three pieces with seams or something to get it to fit on a normal size printer.


2thlesswithta2s

Active Member
First Name
Ron
Joined
May 17, 2026
Threads
0
Messages
26
Reaction score
30
Location
NY
Vehicles
Subaru Toyota
Slatelets and headlight covers look pretty easy to design and print. Any info on the dimensions of the area between the headlights? I'm guessing we'll have to break it up into three pieces with seams or something to get it to fit on a normal size printer.
They will have stl files & design dimensions available. Everything is intended to be open source. You can use a print service to get large prints. Here's one. There are others.

https://partguys.io/

OP
OP
htmlprofessional

htmlprofessional

New Member
Joined
May 29, 2026
Threads
1
Messages
4
Reaction score
0
Location
MT
Vehicles
audi
They will have stl files & design dimensions available. Everything is intended to be open source. You can use a print service to get large prints. Here's one. There are others.
Thanks for the feedback, but I'd rather DIY the whole thing then pay a couple hundred dollars to a print service. Worse case I would buy my own super expensive printer. I'm just trying to get an idea of which way would work best based on how big it is.


KevinRS

Well-Known Member
First Name
Kevin
Joined
Jul 4, 2025
Threads
5
Messages
1,387
Reaction score
1,600
Location
California
Vehicles
Nissan Versa
Thanks for the feedback, but I'd rather DIY the whole thing then pay a couple hundred dollars to a print service. Worse case I would buy my own super expensive printer. I'm just trying to get an idea of which way would work best based on how big it is.
One issue is materials. You don't really want standard PLA on a car part unless you are just prototyping or maybe putting on a holiday light cover you will be taking off in a few weeks anyway. You need heat resistance, and also UV resistance for parts that will be external.


Adam W

Well-Known Member
First Name
Adam
Joined
Apr 26, 2025
Threads
6
Messages
265
Reaction score
785
Location
Washington
Vehicles
Honda CRV
I believe they also said they will be selling blanks of some parts, presumably the same injection molded plastic and quality as the OEM parts. Then DIY-ers just need to CNC route out their custom designs. Might be a better option than 3D printing the full piece.


2thlesswithta2s

Active Member
First Name
Ron
Joined
May 17, 2026
Threads
0
Messages
26
Reaction score
30
Location
NY
Vehicles
Subaru Toyota
One issue is materials. You don't really want standard PLA on a car part unless you are just prototyping or maybe putting on a holiday light cover you will be taking off in a few weeks anyway. You need heat resistance, and also UV resistance for parts that will be external.
Probably polycarbonate or nylon would be the best choices for consumer printing. PEEK would be good for commercial grade.


KevinRS

Well-Known Member
First Name
Kevin
Joined
Jul 4, 2025
Threads
5
Messages
1,387
Reaction score
1,600
Location
California
Vehicles
Nissan Versa
Probably polycarbonate or nylon would be the best choices for consumer printing. PEEK would be good for commercial grade.
That's the thing, those materials aren't exactly entry level materials in 3d printing. Even ABS and ASA are not printable on all printers.

OP
OP
htmlprofessional

htmlprofessional

New Member
Joined
May 29, 2026
Threads
1
Messages
4
Reaction score
0
Location
MT
Vehicles
audi
That's the thing, those materials aren't exactly entry level materials in 3d printing. Even ABS and ASA are not printable on all printers.
I'm planning on doing ASA. I've already setup my air filtration system. It wasn't that hard or expensive.

OP
OP
htmlprofessional

htmlprofessional

New Member
Joined
May 29, 2026
Threads
1
Messages
4
Reaction score
0
Location
MT
Vehicles
audi
I guess I can just ballpark it. The front of the slate is about 70 inches wide, which would make that grill about 28 inches by 8 inches. That converts to about 700 mm. So outside pieces would be 200mm(maybe a little more) and inside piece would be 300mm.


2thlesswithta2s

Active Member
First Name
Ron
Joined
May 17, 2026
Threads
0
Messages
26
Reaction score
30
Location
NY
Vehicles
Subaru Toyota
That's the thing, those materials aren't exactly entry level materials in 3d printing. Even ABS and ASA are not printable on all printers.
An FDM printer capable of 300C with an enclosure should be able to handle it, but might need extra tuning & operator competence. Filament would also need to be dried, especially for nylon.


jhevil

New Member
First Name
JH
Joined
Jun 7, 2026
Threads
1
Messages
2
Reaction score
3
Location
US
Vehicles
F-150 Lightning BEV
I believe they also said they will be selling blanks of some parts, presumably the same injection molded plastic and quality as the OEM parts. Then DIY-ers just need to CNC route out their custom designs. Might be a better option than 3D printing the full piece.
I'd love to see this at a reasonable price. Can you share where you saw / heard that the covers would be whole and premade for end users to customize? I cant seem to find it. I already have a capable 3D printer that can handle more difficult materials, but I will avoid taking that route if I can CNC a tough part.

I have several ideas to take the stock signal covers and cut them directly or (more likely) use the stock covers as a template so that I can print my own if the STL files are not readily available.


Adam W

Well-Known Member
First Name
Adam
Joined
Apr 26, 2025
Threads
6
Messages
265
Reaction score
785
Location
Washington
Vehicles
Honda CRV
Can you share where you saw / heard that the covers would be whole and premade for end users to customize? I cant seem to find it. I already have a capable 3D printer that can handle more difficult materials, but I will avoid taking that route if I can CNC a tough part.
It was mentioned at an early press event / design studio tour. Here's a closeup of a poster from the TopSpeed writeup. It's the same event from this Rich Rebuilds video, though I don't remember if he touches on this specific aspect.
